IF-25 – 25 Amp Three Phase Induction Forge

Overview
The IF-25 is a high-performance, three-phase induction forge designed for demanding workshop and light industrial use. With a 15 kW power input and solid-state control, it delivers fast, repeatable heat for forging, brazing, and heat treatment applications. Compact yet powerful, the IF-25 offers precision, reliability, and long service life under continuous operation.

Key Features & Benefits

  • Operates on 208–240 V three-phase power for stable, high-efficiency output

  • 15 kW input power delivers strong, consistent heating for larger stock and high-throughput applications

  • Auto-tuning frequency range from 30 to 80 kHz for optimal coil matching and energy efficiency

  • Solid-state design with minimal maintenance and high reliability

  • Built-in protection against over-current, over-voltage, low water pressure, and overheating

  • 80 percent duty cycle for continuous operation with defined cooling intervals

  • Compact, portable unit measuring approximately 18 x 8 x 17 inches and weighing around 20 kg

Technical Specifications

Specification Value
Input Voltage Three-phase 208–240 V, 50/60 Hz
Maximum Input Current 40 A
Maximum Input Power 15 kW
Frequency Range 30–80 kHz
Duty Cycle 80 percent
Cooling Requirement 22,000 BTU/hr (10 L/min at 0.4 MPa)
Dimensions 18 x 8 x 17 in (46 x 20 x 44 cm)
Weight 44 lb (20 kg)

Applications

  • Forging and heating larger sections of round or flat stock

  • Preheating for forming, bending, or hot assembly work

  • Brazing and shrink-fitting components

  • Heat treatment processes including hardening and tempering

  • Suitable for workshops, production lines, and small industrial facilities

Operation & Safety

  • Always ensure proper water cooling; the unit includes automatic shutdown for low flow or pressure

  • Maintain the rated 80 percent duty cycle for reliable long-term use

  • Solid-state components and built-in diagnostics safeguard against overload and overheating

  • The automatic frequency adjustment system ensures consistent performance across varying coil types and materials

Warranty & Support

Each IF-25 Induction Forge is backed by InductionForges.com’s one-year warranty covering parts and labour under normal operating conditions.
Comprehensive technical support, spare parts, and servicing are available directly through InductionForges.com.
